Spartan Turbo Charger For Ford Ranger & Mazda BT-50 3.2L P5AT with Gaskets

SKU: STS-812971
$2,500.00
Tax included


No compromise, all or nothing, simply THE BEST BOLT ON HIGH FLOW TURBOS ON THE MARKET!

Spartan Turbo chargers are the best in the business, from the build quality, to the bearings, the highest flowing wheels on the market, and their state of the art workshop here in Australia, backed by a 12 Month Warranty.

Spartan Turbos are designed to get the most out of Factory Frame Turbos, meaning entirely bolt on, but having the performance of universal turbo kits. There is also no need for exchange, if you buy a Spartan, you get an entirely new turbo with gaskets, ready to bolt on!

Delivery and Shipping

All orders over $350 and shipped within Australia are FREE STANDARD SHIPPING!!!

WE SHIP INTERNATIONALLY!

We also offer instore pickup at: Demon Pro Parts, 1/107 Wells Rd Chelsea Heights, Vic, 3196

Need your parts ASAP? We also Offer Express Shipping at Checkout!

Want it EVEN FASTER?! Call our team today about Overnight Shipping on 03 8766 8888

The Run Down:

Spartan Turbocharger Systems (S.T.S.) have specially made these turbochargers to help Ranger & BT-50 owners get the most out of their 3.2L P5AT Engines!
To have a turbocharger that can make big HP and stay reliable at the same time is always the dream!
S.T.S. spec these units out with the best of the best parts!
They are designed to make up to 30PSI reliably, yet they also lower EGTs, EMP & drive better than your factory P5AT turbo!
Through vigorous testing they can comfortably say that these units make between 190Whp-230Whp. (Dependent on vehicle set up & tuner)

Features:

- Boost rating 16PSI - 30PSI
- 46mm 6+6 blade billet aluminium compressor wheel
- 9 Blade inconel hybrid turbine wheel
- Custom heavy duty bearing
- Oil cooled core
- Designed specifically for the 3.2L P5AT Engine
- Direct install, no modification required
- Comes with OEM Hella actuator

Specs:

 Compressor Turbine
Core
Inlet: 3 Inch Inlet: Factory Flange Lubrication: Oil
Outlet: Factory Size Outlet: Factory flange Coolant: N/A
Wheel: 46mm 6+6 Billet Aluminium Wheel: 9 Blade Inconel Hybrid Oil Fittings: Factory
Size: Factory AR. Size: Factory AR.93 Coolant Fittings: N/A



Fitting Notes:

The 812971-STS is a 100% direct fit to your Ford Ranger PX/PX2/PX3 & BT-50 UP/UR with the 3.2L P5AT Duratorq engine.
You will require a 3 Inch exhaust system, upgraded intercooler, 30% larger injector nozzles & a custom ECU tune.
(A copy and paste tune wont work on these Turbos)

BUNDLE DEAL!
Buy any 3.2L P5AT turbo and receive a 20% discount on a new oil feed pipe
Discount automatically applied at checkout.

Brand: Spartan Turbocharger Systems (S.T.S.)
Model: 812971-STS
Part No: 812971-0006 / 812971-5006S / 812971-0002 / 812971-5002S / 798166-0007 / 798166-5007S / 853333-5001W / 889939-5001S / 889939-0001 / 889939-5001 / 889939-1 / 822182-5009S / 822182-5009 / 822182-9 / 822182-0009 / 822182-5005S / 822182-5005 / 822182-5 / 822182-0005 / 822182-5007S / 822182-5007 / 822182-7 / 822182-0007 / 822182-5011S / 822182-5011 / 822182-11 / 822182-0011 / 822182-5014S / 822182-5014 / 822182-14 / 822182-0014 / 822182-5010S / 822182-5010 / 822182-10 / 822182-0010 / 822182-5004S / 822182-5004 / 822182-4 / 822182-0004 / 889939-5001W
OEM Part No: UH0513700 / BK3Q6K682RC / BK3Q6K682AB / BK376K682AB / BK3Q6K682AC / FB3Q6K682DF / FB3Q-6K682-DF / FB3Q-6K682-DB / FB3Q6K682DB / FB3Q-6K682-DD / FB3Q6K682DD / FB3Q-6K682-DE / FB3Q6K682DE / FB3Q-6K682-PA / FB3Q6K682PA / FB3Q-6K682-PB / FB3Q6K682PB / FB3Q-6K682-PC / FB3Q6K682PC / FB3Q-6K682-PD / FB3Q6K682PD / FB3Q-6K682-PE / FB3Q6K682PE / FB3Q-6K682-AD / FB3Q6K682AD
Vehicle:
- Ford Everest (UA) 3.2L P5AT MY15-Onwards
- Ford Ranger PX1 3.2L P5AT MY11-15

- Ford Ranger PX2 3.2L P5AT MY15-19
- Ford Ranger PX3 3.2L P5AT MY19-Onwards
- Mazda BT-50 (UP) 3.2L P5AT MY11-15
- Mazda BT-50 (UR) 3.2L P5AT MY15-Onwards
Cooling: Oil only
Actuator: This turbo comes with a genuine OEM Hella electronic actuator
Gaskets: This turbo comes with a free complete gasket kit.
Warranty: 12 Months/25,000km - Whichever comes first
Delivery: Free post to Aus wide, normally takes 2-4 days to major cities.
